Name: Cemetery Interments

Display Field: PLOT_NAME

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: Paper documents are the official records for who is buried where, but this information is also vigilantly maintained in a database. The contents of that database are regularly used to update this layer via a scheduled automation script.Interment points are placed within the plot (polygon) that the person is buried in, but the exact latitude/longitude of the burial is adjusted for cartographic purposes. The 2D map of the cemetery does not show depth, by definition. X, Y coordinates are used, not Z. Two vaults that are vertically on top of one other in the Z plane of the physical world are placed one above the other in the Y plane in the 2D map. The interment points are placed one foot from the left edge to allow the person's name to be labeled on the right. When interment points are labeled, their names might just "spill over" into neighboring plots to the right. This does not mean that the person is buried across two plots; this is merely a digital cartographic issue.Field Descriptions:PLOT_NAME: The name, or address, of the plot of the interment. The format of this name is: section letter, three-digit (0-padded) block number, two-digit (0-padded) plot number. For example, D04210 is in section D, block 42, plot 10SECTION: The section letter of the intermentBLOCK_NUMBER: The block number of the interment, as an integerPLOT_NUMBER: The plot number of the interment, as an integerSEQUENCE_NUMBER: The sequence number of the interment, as a 1-based integer. The first interment in a plot gets a sequence number of 1. The second interments gets a value of 2 and so onINTERRED: The name of the interred person. The format of this value is Last Name, comma, First and subsequent names and titlesBIRTH_DATE: The interred person's date of birth. In some very old cases, this might be an estimate. These dates are localDEATH_DATE: The interred person's date of death. In some very old cases, this might be an estimate. These dates are localAGE: The age of the person, in years, at the time of death. Although time zone is not considered, month and day are. Meaning, the calculated age is not simply the year of death minus the year of birthFUNERAL_DATE: The date of the interred person's funeral. This date hasn't always been tracked, so many values are Null, meaning we don't know the date the funeral was heldSURNAME_SOUNDEX: Four-character Soundex value as calculated by the algorithm found at the National Archive's website, https://www.archives.gov/research/census/soundexLABEL_ROTATION: A 0-degree based angle (where 0 is to the east) specifying how much to rotate the label of the person's name on the map. Default 0VETERAN: A Yes/No value indicating if the interred person was a veteran of the United States military

Service Item Id: a48b69119e6f441984377da18d2edf60

Copyright Text: City of Orem

Default Visibility: true

MaxRecordCount: 1000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 250

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: false

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1950980.4493204653
YMin: 723541.2849918157
XMax: 1952147.5578786433
YMax: 725264.7526734769
Spatial Reference: 32043  (32043)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSMSCircle
Color: [0, 77, 168, 255]
Size: 4.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[115, 178, 255, 255] Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerPointLabelPlacementCenterRight
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 77, 168, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 12
Font Family: MS Gothic
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 75.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: Mapping ID )
• Shape ( type: esriFieldTypeGeometry, alias: Point )
• INTERRED ( type: esriFieldTypeString, alias: Interred Name, length: 100 )
• SURNAME_SOUNDEX ( type: esriFieldTypeString, alias: Last Name Soundex, length: 5 )
• BIRTH_DATE ( type: esriFieldTypeDate, alias: Birth Date, length: 8 )
• DEATH_DATE ( type: esriFieldTypeDate, alias: Death Date, length: 8 )
• AGE ( type: esriFieldTypeSmallInteger, alias: Age )
• FUNERAL_DATE ( type: esriFieldTypeDate, alias: Funeral Date, length: 8 )
• VETERAN ( type: esriFieldTypeString, alias: Veteran, length: 3 , Coded Values: [Yes: Yes] , [No: No] )
• PLOT_NAME ( type: esriFieldTypeString, alias: Plot Name, length: 6 )
• SECTION ( type: esriFieldTypeString, alias: Section, length: 1 )
• BLOCK_NUMBER ( type: esriFieldTypeSmallInteger, alias: Block # )
• PLOT_NUMBER ( type: esriFieldTypeSmallInteger, alias: Plot # )
• SEQUENCE_NUMBER ( type: esriFieldTypeSmallInteger, alias: Burial # )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
